Email

Selecting the Email icon from the Data Manager toolbar allows you to send a saved data or image file as an attachment using e-mail. To use this feature, you must install an e-mail client, and then either link your existing e-mail address to the client, or create a new address. The following instructions are intended as a guide only.

► To attach a file from a Data Manager folder to an e-mail:

The Email feature uses your system default email client. Refer to Windows Help for instructions on setting your default e-mail client. For an example on how to setup an e-mail client, see E-Mail Client Setup.

1.

From the Data Manager main screen, select a file from within one of the folders (e.g. Camera, Scanner Data, Scope Multimeter, etc). In this example (Figure 12‑3). a Vehicle Systems Report was chosen from the Vehicle Systems Report Data Folder.

2.

With the file highlighted, select Email from the toolbar.



3.

A new e-mail message window will display onscreen (Figure 12‑4).



4.

Enter the e-mail address of the recipient, and any other information needed.

5.

Select the Send icon to send the e-mail.

You must have an Internet connection to send e-mail.
